Simulated Sine Wave 400-2000VA UPS Uninterruptible Power Supply
1000VA/600W LED
battery：12V7AH×2
Voltage range：110V(81-134)/120V(89-145)
Frequency：＞40 Hz(Auto sensing)
Voltage range： 110/120VAC ±10%
Frequency range(battery mode)：60/50±1Hz
Transfer time：Typical 4-8ms, 13ms max
Waveform (Batt.mode)：Simulated sine wave
Charging time: 6.5 hours to full charge
4 US standard plugs and sockets
Product size:345*123*189mm
0086 18958987897
bxst025@bao-xiang.com
| BX-UP012 | ||||||
| Capacity | 1000VA/600W | |||||
| Voltage | 220Vac/230Vac | |||||
| Voltage Range | 140-290Vac/140-300Vac | |||||
| Frequency Range | >40 Hz(auto sensing） | |||||
| Voltage Regulation(Batt.Mode) | 220Vac/230Vac±10% | |||||
| Frequency Range(Batt.Mode) | 50Hz±1Hzor60Hz±1Hz(auto sensing) | |||||
| Transfer Time | Typical 2-8ms,13ms max | |||||
| Wavelorm(AC.Mode) | Sine Wave | |||||
| Waveform(Batt.Mode) | Simulated Sine Wave | |||||
| USB charger | 5V/2.0A MAX | |||||
| Battery Voltage | 24V | |||||
| Battery number | 7AH*2 | |||||
| Maximum Charge Current | 1.0A | |||||
| LED display | Power on | Colorful and changeable LED | ||||
| AC Mode | Green LED breath | |||||
| Battery Mode | Yellow LED breath | |||||
| Fault | Red LED lighting | |||||
| Full Protection | short circuit,Overload,Overcharge and overdischarge protection | |||||
| Battery mode | Sounding every 10 seconds | |||||
| Low Battery | Sounding every second | |||||
| Overload | Sounding every 0.5 seconds | |||||
| Fault | Continuously sounding | |||||
|
Approx.Dimension D X W X H(mm） |
345X123X189 | |||||
| Approx Net Weight (kgs) | 8.7 | |||||
| Humidity | 0-90%RH@0-40°C(non-condensing | |||||
| Noise Level | Less than 40dB(1m spacing) | |||||
| Communication port | For choice(USB&RJ45) | |||||
