BX-SL005 sensitive Waterproof Light control environmental protection

Power source: 220-240V/AC
Power frequently: 50/60Hz
Light-control: 8~30LUX
In front of the light control sensor there should be no obstruction affecting it to accept natural light;
In front of the light control sensor there should be no swaying object.

Features

1. with internal environment illumination automatic detection circuit,sutomatically shut down during the day, automatically open in the evening.

2. the  conventional three-wire system(customizable four wire).compatible with a variety of load impedance,sensibility,capacitive lamp.

3. the comtrol object for LED lamp, energy-saving lamp,flourescent lamp, the lamp of incandescent lamp,exhaust,etc.

4. with 5-10 seconds delay when environmental conditions change functions,such as leaves and flying car lighting,lighting,short time delay protection function.


Application



Widely used in street lights, highways, gardens, airports, schools, factories, farms and other places.


Warning



Do not install in the light, need to install in the sun, above the light.



Specifications Voltage  Ated load Working temperature Open circuit losse
SL005-Three Line

AC165-220V、AC/DC12V、

DC24V、DC36V、DC48V、DC60V


3A/6A/10A/16A -40℃~70℃ <1w<1watts
SL005-Four Line

AC165-220V、AC/DC12V、

DC24V、DC36V、DC48V、DC60V

3A/6A/10A/16A
-40℃~70℃
<1w<1watts
