Brand: Wenzhou BXST/OEM/ODM
Model Number: BX-V048-SA
Work voltage: 220V
Frequency: 50/60Hz
Current: 13A
Delay time: 2M/90S (with Quick-start Button)
Under voltage:165V
Over voltage: 260V
Warranty lamp:1 year
Voltage protectors are used when voltage current surges beyond rated value. These units quickly cut power to avoid damage or even fire within your refrigerators, air conditioners, heaters, coolers, freezers, etc.
Voltage protectors feature: bright LED lighting, easy installation, single output, and cutoffs of under voltage .
1.Product Specification
Working Voltage |
220V |
Frequency |
50Hz/60Hz |
Current |
13A |
Under Voltage |
165V |
Over Voltage |
260V |
Max Power |
2860W |
Delay time |
3m /Customized |
Warranty Period | 1 year |
Temperature |
-5℃~+55℃ |
Operating Humidity |
≤ 90% RH |
Material |
PC V0 Flame Retardant |
Application |
air-conditioner/fridge/Water heater etc |
2.Product Features
1.Over/Under Voltage Protection: When the voltage exceeds the limit, it will automatically cut off the power to prevent the electrical appliances being damaged by the too low or too high voltage.
2.Lightning Protection: Instantaneous voltage exceeds the limit, the product will protect the electrical appliance against excessive voltage damage automatically and quickly.
3.Phosphor Bronze: with good electrical conductivity, corrosion resistance and wear resistance.
4.Flame Retardant Material: Be able to reach the experimental standards of level test of UL94-5VA..
5.Child Safety Socket:Only by inserting a plug, with a top pin, can the shutter be opened, which in turn activates the live part of the socket. For a child to get an electric shock, therefore, it needs to not only stick their finger deep into the top hole, but also one of the other holes.
6.Visualized Window:The digital display shows the current working status clearly and conspicuously.
3.Product Advantages
1.750 degrees high temperature resistant;
2.Germany bell plastic shell;
3.The level where V0 flame retardant;
4.Hardware is 0.7 thick beryllium bronze;
5.Relay is sky-wave domestic first-line brand high quality relays;
6.All chip in Taiwan, the United States imported original brand;
7.Every product has a patent of the original.
4.Warning
1.The total power of connected electrical equipment shall not exceed the rated power.
2.Do not use this product in damp or not ventilated environment.
3.Non-professionals do not open, change, repair the product.
4.Poor connection of the front terminal or poor connection of the plugmay cause a danger.
