BX-V010-120V US Adjustable Voltage Protector for Air Conditioner

Brand: BXST
Model Number: BX-V010-120V
Working voltage: 110VAC/50HZ-60HZ
Under voltage: 90-105VAC(adjustable)
Over voltage: 140VAC
Working current: 20A(13106BTU)2400W MAX

      BX-V010-110V is a hot-sold voltage protector in South America.It’s used for refrigerator,water heater and home appliance which power is less than 2400W.


1.Product Specification

Brand Name
BXST
Model Number
BX-V010-120V
Usage
power
Phase
Single Phase
Current Type
AC
Working voltage
120VAC/50HZ-60HZ
Under voltage
90-105VAC(adj)
Over voltage
140VAC
Working current
20A(13106BTU)2400W MAX
Delay time
3mins
Warranty
1 year
Temperature
-5℃~+55℃
Weight
150g
Size
80*35*120mm
Material
Flame retardant PC

2.Product Features

      1.Over/Under Voltage Protection: When the voltage exceeds the limit, it will automatically cut off the power to prevent the electrical appliances being damaged for too low or too high voltage.

      2.Lightning Protection: Instantaneous voltage exceeds the limit, the product will protect the electrical appliance against excessive voltage damage automatically and quickly.

      3.Phosphor Bronze: with good electrical conductivity, corrosion resistance and wear resistance.

      4.Flame Retardant Material: reach the level test experimental standards of UL94-5VA..



3.Warning

      1.The total power of connected electrical equipment shall not exceed therated power.

      2.Do not use this product in damp or not ventilated environment.

      3.Non-professionals do not open, change, repair the product.

      4.Poor connection of the front terminal or poor connection of the plugmay cause a danger.









Q:Are you a factory?
A:Yes,we are a factory which has been focusing on research and development and manufacturing all kinds of socket for 10 years.

Q:What if there is some problems with your products after I receive the bulk?
A:The rate of our qualified products is 99%-100%.If some products are not working when you receive them,we will supply you
the same quantity qualified products.

Q:What is the material of your products?
A:  The shell material is ABS, PC, PA66, V0 Flame-retardant level. Hardware is 0.7 mm thick of beryllium bronze. Our company
uses relay with high quality which is bought from Sky-Wave and Loose Joy. All chips are imported from Taiwan and United States.

Q:How can I get some samples?
A:All the sample is available in stock, we can send you free sample if you can pay the express fee.

Q:How does your factory do regarding quality control?
A:We have professional QC department, we inspect all steps from the purchase of the materials to the departures of products
from our factory according to the standard test. We always attach great importance on quality control from the beginning to the end .

Our factory has gained CE.FCC.Rohs ceritificate.

Q:When you ship my order?
A:Normally 30to45days after receiving your payment,but it can be negotiated based on production schedule.

Q: How long is the product warrenty period?
A:Every products has the patent of the original, we promise that the products have two year warrenty, but the counterfeit products
are not included in the warrenty period

Q: How to identify the quality goods is BXST?
A:We all have anti-counterfeiting qr code on each PCB circuit boards

If you want to know more, please contact us, we will get back to you as soon as possible!
