BX-S162 surge protctor SPD Smart Voltage Relay Surge Protector with US Standard 1-Outlet Power Switch

Brand: BXST
Model Number: BX-S162
Work voltage: 120V
Frequency:50/60Hz
Joule:918J
Peak Voltage:6KV
Peak Current:5kA
Elevtrical noise:<30db




1.Product Specification

Work Voltage

AC120V

Frequency

50/60Hz

Joule

918J

Peak Voltage

6KV

Peak Current

5kA

Electrical noise

30db

Maximum Operating current

≤15A

Size

70*45*54mm

Work environment

-10 ~ +65℃



2.Product Features

      1.Over/Under Voltage Protection: When the voltage exceeds the limit, it will automatically cut off the power to

prevent the electrical appliances being damaged for too low or too high voltage.

      2.Lightning Protection: Instantaneous voltage exceeds the limit, the product will protect the electrical appliance

against excessive voltage damage automatically and quickly.

      3.Phosphor Bronze: with good electrical conductivity, corrosion resistance and wear resistance.

      4.Flame Retardant Material: reach the level test experimental standards of UL94-5VA..



3.Warning

      1.The total power of connected electrical equipment shall not exceed therated power.

      2.Do not use this product in damp or not ventilated environment.

      3.Non-professionals do not open, change, repair the product.

      4.Poor connection of the front terminal or poor connection of the plugmay cause a danger.












Q:Are you a factory?
A:Yes,we are a factory which has been focusing on research and development and manufacturing all kinds of socket for 10 years.

Q:What if there is some problems with your products after I receive the bulk?
A:The rate of our qualified products is 99%-100%.If some products are not working when you receive them,we will supply you the same quantity qualified products.

Q:What is the material of your products?
A:  The shell material is ABS, PC, PA66, V0 Flame-retardant level. Hardware is 0.7 mm thick of beryllium bronze. Our company uses relay with high quality which is bought from Sky-Wave and Loose Joy.

All chips are imported from Taiwan and United States.

Q:How can I get some samples?
A:All the sample is available in stock, we can send you free sample if you can pay the express fee.

Q:How does your factory do regarding quality control?
A:We have professional QC department, we inspect all steps from the purchase of the materials to the departures of products from our factory according to the standard test. We always attach great importance on quality control from the beginning to the end . Our factory has gained CE.FCC.Rohs ceritificate.

Q:When you ship my order?
A:Normally 30to45days after receiving your payment,but it can be negotiated based on production schedule.

Q: How long is the product warrenty period?
A:Every products has the patent of the original, we promise that the products have two year warrenty, but the counterfeit products are not included in the warrenty period

Q: How to identify the quality goods is BXST?
A:We all have anti-counterfeiting qr code on each PCB circuit boards

If you want to know more, please contact us, we will get back to you as soon as possible!
